(Specification )技术参数
|
Model NO. |
型号 |
DF-350S-CMP |
|
Control Method |
控制方式 |
触摸屏控制 |
|
PCB Size (mm) |
PCB尺寸 |
Max.350mm(Nonstandard 非标型号 Max.450mm) |
|
Conveyor Speed |
传输速度 |
0-2600mm/min |
|
Pre-heating Zone |
预加热区 |
Length:1800mm(600*3)Room Temperature-250℃ 长度:1800mm(600*3每段独立控温)温度:室温-250℃ |
|
|
预热功率 |
9KW |
|
|
控制方式 |
PID+SSR模式 |
|
Solder Pot Temperature |
锡炉温度 |
Room Temperature-300℃ |
|
|
锡炉功率 |
10.8KW |
|
PCB Conveyor Direction |
PCB板传送方向 |
L→R/L←R |
|
PCB Conveyor Height |
PCB板传送高度 |
750±20mm |
|
PCB Conveyor Angle |
PCB板过锡角度 |
3-7℃ |
|
Flux Spraying Pressure/Flow Rate |
松香喷泉雾气压/流量 |
5-6kgf/cm 10-100ml/min |
|
Flux Capacity |
松香容量 |
Approx.20Liters |
|
Spraying Nozzle Move |
喷头移动方式 |
Cylinder 无杆气缸 |
|
Nitrogen Consumption |
氮气消耗量 |
|
|
Solder Pot Capacity |
锡炉容量 |
Approx.400kg |
|
Solder Type |
适用焊料类型 |
Lead-free Solder/Normal Solder 无铅焊料/普通焊料 |
|
Normal Power/Start up Power |
正常/起动功率 |
Approx.8KW/30KW |
|
Power Supply |
电源 |
3 phase 5 wires 380V 50/60Hz 三相五线制 |
|
Outside Dimension |
设备外形尺寸 |
L4800*W1300*H1700mm |
|
Weight |
重量 |
1300kg |
